Offset Soybean Plant Ink Printing Eco Friendly Fast Drying Non Skinning
| MOQ: | 1 |
| Price: | $2.96-3 |
Eco Friendly Soybean Plant Ink
,Fast Drying Non Skinning Printing Ink
,Soybean Oil Sheet Fed Offset Ink
| SOYBEAN OIL SHEET-FED OFFSET INK PROCESS CMYK - QUICKSET / OXIDATIVE DRYING |
Series SOY-SF Document TDS-SOY-SF-01 Revision 01 Issue Date 29 Jul 2026 |
FORDIA Soybean Oil Sheet-fed Offset Ink is a conventional process ink series formulated with soybean oil and selected vegetable-oil-based binders for commercial and non-food packaging printing. It is designed for clean transfer, fast setting, stable ink-water balance, sharp dot reproduction and reliable performance on modern high-speed sheet-fed presses.
- Soybean-oil-based vehicle system with a target formulation suitable for a renewable-resource product positioning.
- High colour strength and clean, transparent process shades for low ink-film application.
- Quick setting with balanced oxidative drying for efficient work-and-turn and post-print handling.
- Stable ink-water balance, good fountain-solution tolerance and reduced emulsification tendency.
- Smooth transfer, sharp dots, low misting and controlled tack for coated and uncoated paper grades.
- Good gloss and rub resistance after full drying.
| Recommended | Not Recommended / Requires Prior Testing |
|---|---|
| Commercial printing, books, brochures, catalogues | Synthetic paper, plastic film, foil and metallised non-absorbent stock |
| Paper and paperboard, coated and uncoated | Direct food-contact applications |
| Straight and perfecting sheet-fed offset presses | Low-migration or sensitive food-packaging applications unless separately validated |
| Inline or offline aqueous coating after compatibility testing | UV curing, LED curing or heatset web offset presses |
| Property | Typical Target | Test / Condition | Remarks |
|---|---|---|---|
| Ink type | Conventional sheet-fed quickset | Visual / formulation | Oxidative drying |
| Appearance | Smooth homogeneous paste | Visual | Free from hard particles |
| Colours | Process Yellow / Magenta / Cyan / Black | Standard process series | Special colours on request |
| Soybean oil content | ≥20% w/w target | Formula calculation | Required minimum for ASA SoySeal eligibility for sheet-fed ink; trademark use requires a valid licence |
| Fineness of grind | ≤5 μm | Grind gauge | Typical target |
| Tack | See colour table below | Inkometer, 32°C, 400 rpm, 1 min | Controlled tack for transfer and paper safety |
| Set time | 8-15 min | Standard coated paper, 25°C, 50% RH | Substrate and ink film dependent |
| Surface dry | 4-8 h | Standard coated paper, 25°C, 50% RH | Ventilation and fountain solution affect result |
| Full oxidative cure | 24-48 h | Standard laboratory conditions | Allow longer before demanding finishing |
| Gloss | ≥55 GU | 60° glossmeter on coated stock | Paper-dependent |
| Shelf life | 12 months | Unopened original packaging | 5-30°C, dry storage |
| Colour | Yellow | Magenta | Cyan | Black | |
|---|---|---|---|---|---|
| Tack target | 8.0-9.0 | 8.5-9.5 | 9.0-10.0 | 8.0-9.0 | |
| Control tolerance | ±0.5 | ±0.5 | ±0.5 | ±0.5 | |
| Tack note: Tack must be adjusted to press speed, paper surface strength, room temperature and colour sequence. The values above are starting targets only. | |||||
| Colour | Light Fastness* | Alcohol | Solvent | Alkali | Remarks |
|---|---|---|---|---|---|
| Yellow | 5 | + | + | + | Standard process yellow |
| Magenta | 5 | + | + | - | Alkali-sensitive standard magenta |
| Cyan | 8 | + | + | + | Standard process cyan |
| Black | 8 | + | + | + | Standard process black |
* Blue Wool Scale: 1 = low, 8 = excellent. “+" = resistant under the stated internal test; “-" = not resistant. Confirm actual pigment-grade performance before publication.
- Use the minimum fountain solution required to maintain a clean non-image area; excessive water can slow setting and reduce gloss.
- Maintain stable pressroom temperature and humidity. Condition paper and ink before printing.
- Mix ink thoroughly before use. Avoid uncontrolled addition of reducer, drier, anti-skin agent or varnish.
- For critical paper, perfecting work or high-speed printing, confirm tack and set speed by a production trial.
- Before aqueous coating, lamination, foil stamping, laser printing or other finishing, verify complete drying and compatibility.
- Use clean, compatible conventional offset rollers and blankets. This product is not designed for UV/LED systems.
Process shades may be formulated to target ISO 2846-1 colour characteristics, and production may be controlled according to ISO 12647-2. Compliance must be demonstrated using the actual ink, substrate, ink-film thickness, press conditions and measurement data. This TDS does not by itself constitute ISO certification.
- Store tightly closed in the original container at 5-30°C, away from heat, direct sunlight and ignition sources.
- Avoid prolonged exposure to air. Reseal partly used containers immediately and keep the ink surface clean.
- Prevent contamination with water, UV ink, cleaning solvent or incompatible auxiliaries.
- Consult the current Safety Data Sheet (SDS) before handling. Use appropriate gloves, eye protection and local workplace controls.
High gloss finish with ultrafast drying for efficient sheetfed offset printing.
Customizable Pantone colors matched precisely to your brand specifications.
Ecofriendly formulation with low VOC and sustainable raw materials.
Speedy dry technology reduces production time and prevents setoff marks.
Excellent color consistency and adhesion on various coated paper stocks.
