Self Adhesive Underpacking Foil Polyester Underpacking Film For Offset Printing Press

Self Adhesive Underpacking Foil Polyester Underpacking Film For Offset Printing Press

MOQ: 1
Price: $0.10-1
Detail Information
Place of Origin
Germany
Brand Name
FORDIA
Material:
Polyester
Type:
Self-adhesive Or Non-adhesive
Thickness:
0.04-0.35 Mm
Roll Spec:
1080/1300 Mm, 50/100 M Rolls
Chemical Resistance:
Resists Dampening Solutions, Cleaners
Corrosion Protection:
Corrosion-inhibiting Additives
Highlight:

Self Adhesive Underpacking Foil

,

Underpacking Foil Polyester

,

Offset Printing Underpacking Film

Product Description
FORDIA Underpacking Foil
Technical Data Sheet
1. FORDIA Underpacking Foil - Non Adhesive

Product Description:

FORDIA Underpacking Foil (Plate Underlay Foil, Non Adhesive) offers reliable support for adaptation to cylinder circumferences and print lengths in offset printing presses and ensures optimum dot transfer.

The foil can be easily applied beneath printing plates and blankets.

FORDIA PolyFoil consists of a biaxially stretched polyester layer which offers high dimensional stability. The thickness tolerance is low. The material composition provides extremely high resistance to swelling caused by dampening solutions and cleaning agents.

Available Thicknesses
  • 0.04 mm / 0.0016"
  • 0.08 mm / 0.0031"
  • 0.10 mm / 0.0039"
  • 0.12 mm / 0.0047"
  • 0.14 mm / 0.0055"
  • 0.16 mm / 0.0063"
  • 0.18 mm / 0.0071"
  • 0.20 mm / 0.0079"
  • 0.23 mm / 0.0090"
  • 0.25 mm / 0.0098"
  • 0.28 mm / 0.0110"
  • 0.30 mm / 0.0118"
  • 0.35 mm / 0.0140"

Standard Roll Specification:

Roll width: 1080 / 1300 mm

Roll length: 50 / 100 meters

Sheets are also available.

2. FORDIA Underpacking Foil - Self Adhesive

Product Description:

FORDIA Self-Adhesive Underpacking Foil is designed for offset printing applications requiring stable cylinder adjustment. Corrosion-inhibiting additives in the PolyFoil SKL underpacking foil protect the cylinder surface.

The foil can be easily applied to almost all cylinders and can be removed quickly and cleanly with very little cleaning effort.

The release film consists of siliconised polypropylene, which prevents wrinkling and avoids dust inclusion. Due to its high resistance to chemical cleaners and solvents, PolyFoil SKL provides long service life.

Available Thicknesses
  • 0.08 mm / 0.0031"
  • 0.10 mm / 0.0039"
  • 0.12 mm / 0.0047"
  • 0.14 mm / 0.0055"
  • 0.16 mm / 0.0063"
  • 0.18 mm / 0.0071"
  • 0.20 mm / 0.0079"
  • 0.22 mm / 0.0087"
  • 0.24 mm / 0.0094"
  • 0.26 mm / 0.0102"
  • 0.28 mm / 0.0110"
  • 0.30 mm / 0.0118"
  • 0.32 mm / 0.0126"
  • 0.35 mm / 0.0138"
  • 0.40 mm / 0.0157"
  • 0.45 mm / 0.0177"
  • 0.50 mm / 0.0217"
  • 0.55 mm / 0.0237"

Standard Roll Specification:

Roll width: 1080 / 1300 mm

Roll length: 50 / 100 meters

Sheets are also available.
